How long will VSAN rebuilding take with large drives?

· ·

I have seen this question popping up various times now where people want to know how long VSAN rebuilding will take with large drives. And it was something that was asked on twitter as well today, and I think there are some common misconceptions out there when it comes to rebuilding. Maybe this tweet summarizes those misconceptions best:

https://twitter.com/rbergin/status/466908885165424641

There are a couple of things I feel need to be set straight here:

  1. VSAN is an object store storage solution, each disk is a destination for objects
  2. There is no filesystem or RAID set spanning disks

I suggest you read the above twice, now if you know that there is no RAID set spanning disks or a single filesystem formatted across multiple you can conclude the following: If a disk fails then what is on the disk will need to be rebuild. Lets look at an example:

I have a 4TB disk with 1TB capacity used by virtual machine objects. The 4TB disk fails. Now the objects are more than likely out of compliance from an availability stance and VSAN will start rebuilding the missing components of those objects. Notice I said “objects and components” and not “disk”. This means that VSAN will start reconstructing the 1TB worth of components of those impacted objects, and not the full 4TB! The total size of the lost components is what matters, and not the total size of the lost disk.

Now when VSAN starts rebuilding it is good to know that all hosts that hold components of impacted objects will contribute to the rebuild. Even better, VSAN does not have to wait for the failed disk to be replaced or return for duty… VSAN used the whole VSAN cluster as a hot spare and will start rebuilding those components within your cluster, as long as there is sufficient disk capacity available of course. On top of that, the rebuilding logic of VSAN is smart… it will not just go all out but it will instead take the current workload consideration. If you have virtual machines which are doing a lot of IO than VSAN, while rebuilding, is smart enough to prioritize the rebuilding of those components in such a way that it will not hurt your workloads.

Now the question remains, how long will it take to rebuild 1TB worth of lost components? Well that depends… And what does it depend on?

  • Total size of components to be rebuild of impacted objects
  • Number of hosts in the cluster
    • Number of hosts contributing to the rebuild
  • Number of disks per host
  • Network infrastructure
  • Current workload of VMs within the cluster

A lot of variables indeed, difficult for me to predict how long it will take. This is something

Oh, and before I forget, congrats to the VSAN team for winning best of Microsoft TechEd in the virtualization category. WHAT? Yes you read that correctly…

HA restarts in a DR/DA event

· ·

I received a couple of questions last week about HA restarts in the scenario where a full site failure has occurred or a part of the storage system has failed and needs to be taken over by another datacenter. Yes indeed this is related to stretched clusters and HA restarts in a DR/DA event.

The questions were straight forward, how does the restart time-out work and what happens after the last retry? I wrote about HA restarts and the sequence last year, so lets just copy and paste that here:

  • Initial restart attempt
  • If the initial attempt failed, a restart will be retried after 2 minutes of the previous attempt
  • If the previous attempt failed, a restart will be retried after 4 minutes of the previous attempt
  • If the previous attempt failed, a restart will be retried after 8 minutes of the previous attempt
  • If the previous attempt failed, a restart will be retried after 16 minutes of the previous attempt

You can extend the restart retry by increasing the value “das.maxvmrestartcount”. And then after every 15/16 minutes a new restart will be attempted. The question this triggered though is why would it even take 4 retries? The answer I got was: we don’t know if we will be able to fail over the storage within 30 minutes and if we will have sufficient compute resources…

Here comes the sweet part about vSphere HA, it actually is a pretty smart solution, it will know if VMs can be restarted or not. In this case as the datastore is not available there is absolutely no point in even trying and HA as such will not even bother. As soon as the storage becomes available though the restart attempts will start. Same applies to compute resource, if for whatever reason there is insufficient unreserved compute resources to restart your VMs then HA will wait for them to become available… nice right!?! Do note I emphasized the word “unreserved” as that is what HA cares about and not actually about used resources.

Alert: vSphere 5.5 U1 and NFS issue!

· ·

Some had already reported on this on twitter and the various blog posts but I had to wait until I received the green light from our KB/GSS team. An issue has been discovered with vSphere 5.5 Update 1 that is related to loss of connection of NFS based datastores. (NFS volumes include VSA datastores.)

*** Patch released, read more about it here ***

This is a serious issue, as it results in an APD of the datastore meaning that the virtual machines will not be able to do any IO to the datastore at the time of the APD. This by itself can result in BSOD’s for Windows guests and filesystems becoming read only for Linux guests.

Witnessed log entries can include:

2014-04-01T14:35:08.074Z: [APDCorrelator] 9413898746us: [vob.storage.apd.start] Device or filesystem with identifier [12345678-abcdefg0] has entered the All Paths Down state.
2014-04-01T14:35:08.075Z: [APDCorrelator] 9414268686us: [esx.problem.storage.apd.start] Device or filesystem with identifier [12345678-abcdefg0] has entered the All Paths Down state.
2014-04-01T14:36:55.274Z: No correlator for vob.vmfs.nfs.server.disconnect
2014-04-01T14:36:55.274Z: [vmfsCorrelator] 9521467867us: [esx.problem.vmfs.nfs.server.disconnect] 192.168.1.1/NFS-DS1 12345678-abcdefg0-0000-000000000000 NFS-DS1
2014-04-01T14:37:28.081Z: [APDCorrelator] 9553899639us: [vob.storage.apd.timeout] Device or filesystem with identifier [12345678-abcdefg0] has entered the All Paths Down Timeout state after being in the All Paths Down state for 140 seconds. I/Os will now be fast failed.
2014-04-01T14:37:28.081Z: [APDCorrelator] 9554275221us: [esx.problem.storage.apd.timeout] Device or filesystem with identifier [12345678-abcdefg0] has entered the All Paths Down Timeout state after being in the All Paths Down state for 140 seconds. I/Os will now be fast failed.

If you are hitting these issues than VMware recommends reverting back to vSphere 5.5. Please monitor the following KB closely for more details and hopefully a fix in the near future: http://kb.vmware.com/kb/2076392



Updating LSI firmware through the ESXi commandline

· ·

I received an email this week from one of my readers / followers on twitter who had gone through the effort of upgrading his LSI controller firmware. He shared the procedure with me as unfortunately it wasn’t well documented. I hope this will help others in the future, I know it will help me as I was about to look at the exact same for my VSAN environment, thanks for sharing this Tom!

— copy / paste from Tom’s document —

We do quite a bit of virtualization and storage validation and performance testing in the Taneja Group Labs (http://tanejagroup.com/). Recently, we were performing some tests with VMware’s VSAN and due to some performance issues we were having with the AHCI controllers on our servers we needed to revise our environment to add some LSI SAS 2308 controllers and attach our SSD and HDDs to the LSI card. However our new LSI SAS controllers didn’t come with the firmware mandated by the VSAN HCL (they had v14 and the HCL specifies v18) and didn’t recognize the attached drives.  So we set about updating LSI 2308 firmware. Updating the LSI firmware is a simple process and can be accomplished from an ESXi 5.5 U1 server but isn’t very well documented. After updating the firmware and rebooting the system the drives were recognized and could be used by VSAN. Below are the steps I took to update my LSI controllers from v14 to v18. [Read more…] about Updating LSI firmware through the ESXi commandline

VSAN for ROBO?

· ·

I noticed this new SuperMicro VSAN Ready Node being published last week. The configuration is potentially a nice solution for ROBO deployments, primarily due to the cost of the system.

When I did the math it came in around $ 3800,-. This is the configuration:

  • SuperMicro SuperServer 1018D-73MTF
  • 1 x Intel E3-1270 V3 3.5GHz- Quadcore
  • 32GB Memory
  • 5 x 1TB 7200 RPM NL-SAS HDD
  • 1 x 200GB Intel S3700 SSD
  • LSI 2308 Disk controller
  • 4 x 1GbE NIC port

It is a nice configuration that will allow for roughly fifteen 1 vCPU Virtual Machines with 3GB of memory and 60GB disk capacity per host. Personally I would use a different CPU and some more memory probably as that gives you a bit more headroom, especially during maintenance. The cost from a software point of view is socket based so you can increase memory and change the type of CPU with relative low cost impact. The SuperMicro server listed however is limited to the E3 CPU family and to 32GB but there are alternatives out there. (For instance the Dell R320 or maybe even the R210 etc)

From a software point of view the cost of this configuration is limited to 3 x VSAN license and 3 x vSphere. As VSAN even works with Essentials Plus and Standard you could leverage that to keep the cost down, but keep in mind that you won’t have DRS if you drop down to Standard or lower. Still sounds like a nice ROBO package to me, especially when you have many sites this could be a great way to create a standardized packaged solution.
